Factory Supply steel corrugated roof sheet making machine

Product Description

Factory Supply steel corrugated roof sheet making machine
Can Formed Material
GI,AI
Equipment operation
Automatic
Thickness of sheet (mm)
0.3-0.9mm
Material width(mm)
As your requirement
Cover Width of the sheet after formed
as your drawing
Speed
30-40m/min
Diameter of shaft
40mm
Material of rollers
C45 steel quenched and chromed
Motor brand
Siemens or Guomao
PLC
Siemens or Delta or Mitsubushi
Roof sheet Roll Forming Machine features: The color plate equipment using high level of automatic control software, production information management. The entire unit automation control system uses the highly integrated network, causes the automated system performance to be superior.
Roof sheet Roll forming machine is made up of material, molding and post-cutting. The appearance of the color plate is beautiful and even, with high intensity and durable. It is widely used in industrial buildings, such as factory buildings, warehouses, gymnasiums, exhibition halls, theaters and so on. Room and wall. Roof sheet Roll forming machine is made up of material discharge, molding and post-forming cutting. The appearance of products is beautiful and even, with high intensity and durable. It is widely used in industrial buildings, such as factory buildings, warehouses, garages and hangars. , Stadiums, exhibition halls, theaters and other rooms and walls. Its components include: machine, PLC computer control system, hydraulic pump station system, automatic after cutting system equipment
The centerline of the upper and lower rollers of the press tile shall be on the same plane line, with the center wheel as the standard, the flatness shall not be more than 1mm, the gap of the upper and lower rollers of each row shall be equal and the gap deviation shall be 0.1mm. Commission with conventional gauges or feeler gauge. The shape of the plate by the machine roll, both solemn elegance, and beautiful novel, and the appearance of flat, ripple uniform, high utilization rate, intensity,high degree of automation, low cost, durable. PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
Liming Stamping Form Machine Co.,Ltd. occupies an area of 156,000 square meters and 6 large production plants. It has been established in 1996 with many years of production experience, serving 156 countries, 4 international machinery patents, 10 Chinese machinery patents, nationally certified high-tech company.China's top three steel-building materials equipment factories.We brought in the most advanced software and CNC lathes, in order to ensure that every step is in the correct way.
This is the service process we designed for you.
Speed and hardness test
This is our test of the speed and hardness of machine parts to ensure the quality and stable operation of the machine
Our company has a professional quality inspection and after-sales service team, can solve your worries

Q: Can you customize the machine from your company?

A: Of course, we can manufacture the machine according to your customized size demand.

Q: How is the quality? Is there any department related to quality control?

A: All raw materials we use are quality controlled. Workers will take care of every detail when handling production and packaging. The quality control department is responsible for the quality of each process

Q: Is the packaging form?

A: Yes, of course! All our machines will be packaged in dust and water proof, and they can be reinforced after loading to fully meet export packaging standards.

Q: How about after-sales service?

A: TM is online 24 hours a day, and you can also contact them via email, Skype, MSN, whatsapp. and many more Two-year warranty and parts replacement.
